9.2 Backup by CMOS.BIN
9-7
6 Select {CMOS LOAD}. The confirmation dialog box appears.
7 Select {YES}. The loaded CMOS.BIN file contents are reflected in the data in
the robot I/F unit and the CompactFlash of NCP01.
8 Wait for the loading to be com-
pleted.
While loading, the message "Loading system data. Don’t turn the
power off." is displayed.
When the buzzer on the programming pendant sounds and the
message disappears, the load is completed.
Operation Explanation
Short Cut
Main Menu
Maintenance mode
TOOL
SYSTEM INFO
FILE
CF
CompactFlash
CMOS SAVE
CMOS LOAD
SYSTEM RESTORE
Load?
NO
YES
Aa
DISPLAY SETUP
Depending on the version of software, the above-
mentioned message is not displayed. In this
case, confirm that the load is completed by the
buzzer sound of programming pendant.
If it is impossible to confirm by the buzzer, move
the cursor up/down. The cursor does not move
while loading is in progress.
NOTE
