YASKAWA NX100 Instructions

11.1 Addition of I/O Modules
11-3
8 Press [ENTER]. The confirmation dialog box is shown.
9 Select {YES}. The system parameters are then set automatically according to
the current mounted hardware status. The procedure for the addi-
tion of the I/O module is complete.
If there is a difference between the displayed contents and the actual mounted status,
confirm the status again. If the status is correct, the I/O module may be defective: in such
a case, contact your Yaskawa representative.
Operation Explanation
Short CutMain Menu Maintenance mode
IO MODULE
ST# DI DO AI AO BOARD
-
-
-
-
-
-
-
-
-
-
-
-
-
05
06
07
08
09
10
11
12
13
14
15
16
17
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
NONE
NONE
NONE
NONE
NONE
NONE
NONE
NONE
NONE
NONE
NONE
NONE
NONE
Modify?
NO
YES
NOTE

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
