YASKAWA NX100 Instructions

11.2 Addition of Base and Station Axes
11-7
Operation Explanation
5 Select {CONTROL GROUP}. The current control group type is displayed.
6 Point the cursor to the type of
control group to be modified,
and press [SELECT].
The MACHINE LIST window is displayed.
7 Select one in the type list. After the type selection, the window returns to the CONTROL
GROUP window.
8 Press [ENTER] in CONTROL
GROUP window.
The window moves to the CONNECTION window.
Short CutMain Menu Maintenance mode
CONTROL GROUP
: EA1400N-A0
: NONE
: HP20-A0
: NONE
: NONE
: TURN-1
: TURN-1
: NONE
R1
B1
R2
B2
R3
S1
S2
S3
Short CutMain Menu Maintenance mode
MACHINE LIST
NONE
RECT-XYZ
RECT-YZ
RECT-X
RECT-XZ
RECT-Z
RECT-XY
RECT-Y
RECT-X
RECT-Y
RECT-Z
RECT-XY
RECT-YZ
RECT-XYZ
: TRAVEL X-AXIS BASE
: TRAVEL Y-AXIS BASE
: TRAVEL Z-AXIS BASE
: TRAVEL XY-AXIS BASE
: TRAVEL YZ-AXIS BASE
: TRAVEL XYZ-AXIS BASE
(See the figures on the following page.)
