YASKAWA NX100 Instructions

11.2 Addition of Base and Station Axes
11-8
Direction of Base Axis
Z
Y
X
CARTESIAN
X-AXIS
Base axis direction of travel coincides
with robot coordinate X-Axis.
RECT-X
Y
X
CARTESIAN
Y-AXIS
Base axis direction of travel coincides
with robot coordinate Y-Axis.
Z
RECT-Y
Y
X
CARTESIAN
Z-AXIS
Base axis direction of travel coincides
with robot coordinate Z-Axis.
Z
RECT-Z
Y
X
CARTESIAN
X-AXIS
CARTESIAN
Y-AXIS
Base 1st and 2nd axes directions of
travel coincide with robot coordinate
X-Axis and Y-Axis, respecitively.
Z
RECT-XY
Y
X
CARTESIAN
Z-AXIS
CARTESIAN
Y-AXIS
Base 1st and 2nd axes directions of
travel coincide with robot coordinate
Y-Axis and Z-Axis, respectively.
Z
RECT-YZ
Y
X
CARTESIAN
Z-AXIS
CARTESIAN
X-AXIS
Base 1st and 2nd axes directions of
travel coincide with robot coordinate
X-Axis and Z-Axis,respectively.
Z
RECT-XZ
Y
X
CARTESIAN
Y-AXIS
CARTESIAN
X-AXIS
CARTESIAN
Z-AXIS
Base 1st, 2nd, and 3rd axes directions
of travel coincide with robot coordinate
X-Axis, Y-Axis, and Z-Axis, respectively.
Z
RECT-XYZ

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
