YASKAWA NX100 Instructions

13.1 Power Supply Contactor Unit
13-4
Power Supply Unit Configuration (JZRCR-NTU02-)
NJ2096-
DATE
SER NO.
JAPAN
TYPE
YASKAWA ELECTRIC CORPORATION
CN083FU
5A 125V
SS
EE
FF
UU
10A 250V
2FU
CN07 CN06
CN05 CN04
4X
EE
FF
1FU
10A 250V
SS
UU
CN03CN02
CN01 SW1
3X
2X
1X
(CN08)
Brake Output Connector
(CN07)
Robot Connection
(CN06)
External Signal Connector
(3FU)
Fuse for Brake
SDP50 (5A 125V)
Power Supply Contactor
Sequence Circuit Board
JANCD-NTU01-
Main Power Supply
Input
(4X)
(1FU)(2FU)
Fuse for AC Control
Power Supply
326010 (10A 250V)
(CN05)
(CN04)
TU Hot Line I/O
(CN02)
DC24V Input
(S1)
Switch for MECHATROLINK
Station Setting
(CN03)
DC24V Input
(CN01)
Servo I/F
(1KM) Contactor
(2KM) Contactor
(1Z) Line Filter
(1X) Converter Output
(2X) AC Control Power Supply
(3X) AC Fan Power Supply

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
