Input (PV, Remote, and Auxiliary Analog) Functions
SettingDetails
Parameter
symbol
Name Displaylevel Settingrange Menusymbol
PYS
10-segment
linearizer
selection
Group 1, 2: STD
Group 3, 4: PRO
OFF: Disable
PV: PV analog input
RSP: RSP analog input
AIN2: AIN2 analog input
AIN4: AIN4 analog input
PVIN: PV input
OUT: OUT analog output
OUT2: OUT2 analog output
RET: RET analog output
PYS1
PYS2
PYS3
PYS4
A1toA11
10-segment
linearizer
input
Group 1, 2: STD
Group 3, 4: PRO
-66.7 to 105.0% of input range
(EU)
Outputlinearizer:-5.0to105.0%
B1toB11
10-segment
linearizer
output
Group 1, 2: STD
Group 3, 4: PRO
10-segmentlinearizerbias:-66.7
to 105.0% of input range span
(EUS)
10-segmentlinearizer
approximation: -66.7 to 105.0%
of input range (EU)
Outputlinearizer:-5.0to105.0%
PMD
10-segment
linearizer
mode
Group 1, 2: STD
Group 3, 4: PRO
0:10-segmentlinearizerbias
1:10-segmentlinearizer
approximation
Note1: When each parameter is displayed, the group number (1 to 4) is displayed on Group display.
Parameters are set in the following order.
(1) PYS:Specifieswherethe10-segmentlinearizerfunctionisused.
Setpoints PV, RSP, AIN2, and AIN4 function before the input ladder calculation
section.
Setpoint PVIN functions after the input ladder calculation section.
► Wherethe10-segmentlinearizerfunctionisused;Functionblockdiagramsin8.1Setting
Control Mode (CTLM)
(2) PMD:Specifieswhethertouseitasa10-segmentlinearizerbiasora10-segment
linearizerapproximation.
(3) A1toA11,B1toB11:Setsthe10-segmentlinearizerinputand10-segmentlinearizer
output.
For the input range and input range span, the range varies depending on where the
10-segmentlinearizerisused.
PV input and PV analog input: PV input range or PV input range span
RSP analog input: RSP remote input range or RSP remote input range span
AIN2 auxiliary analog input: AIN2 auxiliary analog input range or AIN2 auxiliary
analog input range span
AIN4 auxiliary analog input: AIN4 auxiliary analog input range or AIN4 auxiliary
analog input range span
Note
• Setthe10-segmentlinearizersothatitincreasesmonotonically.
• Ifthesamesetpointissetforthetwoormoreparametersof10-segmentlinearizerselection
(PYS), a smaller group number is used.
7
7.1SettingFunctionsofPVInput,RemoteInput,andAuxiliaryAnalogInput
