YOKOGAWA UP55A User Manual

ii
IM 05P02C41-01EN
Target Readers
This guide is intended for the following personnel;
● Engineersresponsibleforinstallation,wiring,andmaintenanceoftheequipment.
● Personnelresponsiblefornormaldailyoperationoftheequipment.
Notice
● Thecontentsofthismanualaresubjecttochangewithoutnoticeasaresultof
continuing improvements to the instrument’s performance and functions.
● Everyefforthasbeenmadetoensureaccuracyinthepreparationofthismanual.
Should any errors or omissions come to your attention, however, please inform
YokogawaElectric’ssalesofceorsalesrepresentative.
● Undernocircumstancesmaythecontentsofthismanual,inpartorinwhole,be
transcribed or copied without our permission.
Trademarks
● Ourproductnamesorbrandnamesmentionedinthismanualarethetrademarksor
registered trademarks of Yokogawa Electric Corporation (hereinafter referred to as
YOKOGAWA).
● Microsoft,MS-DOS,Windows,WindowsXP,WindowsVista,andWindows7are
either registered trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries.
● Adobe,Acrobat,andPostscriptareeitherregisteredtrademarksortrademarksof
Adobe Systems Incorporated.
● EthernetisaregisteredtrademarkofXEROXCorporationintheUnitedStates.
● ModbusisaregisteredtrademarkofSchneiderElectric.
● PROFIBUS-DPisaregisteredtrademarkofPROFIBUSUserOrganization.
● DeviceNetisaregisteredtrademarkofOpenDeviceNetVenderAssociation,Inc.
● CC-LinkisaregisteredtrademarkofCC-LinkPartnerAssociation(CLPA.)
● WedonotusetheTMor®marktoindicatethesetrademarksorregistered
trademarks in this user’s manual.
● Allotherproductnamesmentionedinthisuser’smanualaretrademarksorregistered
trademarks of their respective companies.
SafetyPrecautions
This instrument is a product of Installation Category II of IEC/EN/CSA/UL61010-1, IEC/
EN61010-2-201, IEC/EN61010-2-030 Safety Standards and Class A of EN61326-1,
EN55011 (EMC Standards).
 CAUTION
This instrument is an EMC class A product. In a domestic environment, this product may
cause radio interference in which case the user needs to take adequate measures.
The instrument is a product rated Measurement Category O (other).
* Measurement Category O (other)
This category applies to electric equipment that measures a circuit connected to a
low-voltage facility and receives power from stationary equipment such as electric
switchboards.
To use the instrument properly and safely, observe the safety precautions described in
this user’s manual when operating it. Use of the instrument in a manner not prescribed
herein may compromise protection features inherent in the device. We assume no liability
for or warranty on a fault caused by users’ failure to observe these instructions.
This instrument is designed to be used within the scope of Measurement Category O
(other) and is dedicated for indoor use.

YOKOGAWA UP55A Specifications

General

Brand	YOKOGAWA
Model	UP55A
Category	Controller
Language	English
