YOKOGAWA UP55A - Setting the Program Time Unit

9-5
IM 05P02C41-01EN
Program Pattern Functions
9
9.1.3 SettingtheProgramTimeUnit
Description
The program time unit is applied to the segment time (TIME), segment ramp-rate (TM.
RT), wait time (WT.TM1 to WT.TM5), time event (T.ON1 to T.ON16 and T.OF1 to T.OF16),
and starting time of program operation (S.TM).
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
TMU Program time unit EASY
HH.MM: hour.minute (when the
segment ramp-rate setting is
selected in the segment setting
method (SEG.T), HH.SS
means "per 1 hour.")
MM.SS: minute.second (when the
segment ramp-rate setting is
selected in the segment setting
method (SEG.T), HH.SS
means "per 1 minute.")
CTL
9.1SettingtheSettingMethodofProgramPattern
