8-51
IM 05P02C41-01EN
Control Functions
8.2.4 PDControl(StableControlinWhichaSetpointisnotExceeded)
Description
This control type performs control in which integral action (I action) is excluded from PID
action.
Set the integral time (I or Ic) to OFF.
It is useful when stable control in which a setpoint is not exceeded is desired for integral
processes in which constant flows are delivered.
The following shows the PID control computation formula.
M
R
∆PV
d
e
P
OUT
+








+
=
•
dt
100
Td
where OUT: control output, e: deviation (PV-SP), P: proportional band, Td: derivative time,
∆PV:PVn-PVn-1(n-1:valuebeforeonecontrolperiod),andMR:manualreset
The following table shows combination of PD control and control mode (CTLM).
Control mode (CTLM)
SGL CAS1 CAS PVSW PVSEL
PD control √ N/A √ √ √
√:Available,N/A:Notavailable
The following table shows combination of PD control and output method.
Outputmethod
Current
output
Time
proportional
output
ON/OFF
output
Position
proportional
output
PD control √ √ N/A √
√:Available,N/A:Notavailable
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
P Proportional band EASY
0.0 to 999.9%
When 0.0% is set, it operates as 0.1%.
PID
D Derivative time EASY
OFF: Disable
1 to 6000 s
MR Manual reset EASY -5.0 to 105.0%
Note1: The PID number (1 to 8, or R) is displayed on Group display while the parameter P,
D, or MR is displayed.
8
8.2SettingControlType(CNT)
