18-21
IM 05P02C41-01EN
Parameters
18
18.2.2 SetupParameters
ControlFunctionSettingMenu(Menu:CTL)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
CTLM Control mode STD
SGL: Single-loop control
CAS1: Cascade primary-loop
control
CAS: Cascade control
PVSW: Loop control with PV
switching
PVSEL: Loop control with PV auto-
selector
* When using the ladder program,
the control mode cannot be
changed.
SGL
CNT Control type EASY
PID: PID control
ONOF: ON/OFF control (1 point of
hysteresis)
ONOF2: ON/OFF control (2 points
of hysteresis)
H/C: Heating/cooling control
Standard type:
PID
Heating/
cooling type:
H/C
ALG PID control mode PRO
0: Standard PID control mode
1: Fixed-point control mode
0
ALNO. Number of alarms PRO 0 to 8 4
ZON Zone PID selection STD
0: Segment PID selection
1: Zone PID selection (selection by
PV)
2: Zone PID selection (selection by
target SP)
4: Zone PID selection (selection by
SP)
5: Local PID selection
* If set to “Segment PID
selection,” allows PID constants
to be selected for each
segments.
* If set to “Zone PID selection,”
automatically selects PID
constants according to the
range set in the Reference
point.
* If set to “Local PID selection,”
local PID is selected irrespective
of the operation modes.
1
SEG.T
Segment setting
method
EASY
TIME: Segment time setting
TM.RT: Segment ramp-rate setting
Note: A change of setting deletes a
program pattern.
TIME
TMU Program time unit EASY
HH.MM: hour.minute
MM.SS: minute.second
HH.MM
PT2.G
Program pattern-2
retransmission
STD
OFF: Not used.
ON: used.
* The controller can serve as a
program pattern generator.
* Retransmission output types
(RTS, O1RS, or O2RS) need to
be set to SP2.
OFF
SMP
Input sampling
period (control
period)
STD
100: 100 ms
200: 200 ms
200
In Cascade control, the following parameters are also displayed for secondary loop. (the LP2 lamp
is lit)
• Parameter: CNT, ALG, ALNO.
The parameter CNT of Loop 2 displays PID and H/C.
18.2ListofParameters
