YOKOGAWA UP55A User Manual

9-45
IM 05P02C41-01EN
Program Pattern Functions
9
9.13 EditingthePrgramPattern
9.13.1 CheckingtheNumberofRemainingSegments
Description
This allows checking the number of the segments unused in the controller.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
ALL.S
Number of
remaining unused
segments
PRO
0 to 300 or 600 (600 when the
option“/AP”isspecied)
(Display only)
EDIT
9.13.2 CheckingtheNumberofSegmentsinspecifiedpattern
Description
This allows specifying the program pattern number to be displayed in the parameter
USE.S.
The parameter PTN.S is displayed when a program pattern number is specified in
the parameter USE.S. The number of segments for the specified program pattern is
displayed in USE.S.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
PTN.S
Pattern number
designation for
comrmingnumber
of segments
PRO
0 to 30 or 99 (99 when the option “/
AP”isspecied)
(Display only)
EDIT
USE.S
Number of
segments within a
pattern
PRO
0: disable
1 to 99
(Display only)
