9.13.3 CopyingaProgramPattern
Description
This function allows copying a created program pattern and editing it as a new program
pattern.
Specify the source-of-copying pattern number in the parameter CPY.S and then press
the SET/ENTER key. Next, specify the destination-of-copying pattern number in the
parameter CPY.D and then press the SET/ETNTER key to perform copying.
At this point, an error may occur. Check the details of the error.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
CPY.S
Source-of-copying
pattern number
designation
PRO
1 to 30 or 99 (99 when the option “/
AP”isspecied)
EDIT
CPY.D
Target-of-copying
pattern number
designation
PRO
1 to 30 or 99 (99 when the option “/
AP”isspecied)
9.13.4 AddingandDeletingSegmentinProgramPatterns
Description
This function allows adding or deleting a segment while or after a program pattern is
created.
WhenthejunctioncodeforasegmentissettoINS.orDEL.,thenextsegmentis
editable. When INS. is set, the segment is added, and when DEL. is set, the segment is
deleted.
Addition and deletion of a segment cannot be done during program pattern operation.
► Clearingallprogrampatterndata:12.2InitializingParameterSettingstoFactoryDefaultValues
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange
Menu
symbol
JC
Junction
code
STD
CONT: Switching for continuation
HOLD: Hold-on switching (the controller holds the
end-of-segment setpoint when the segment is
completed, to perform control).
LOC: Local-mode switching (the controller switches to
a local setpoint when the segment is completed).
REM: Remote-mode switching (the controller
switches to a remote setpoint when the segment is
completed).
W.SW1 to W.SW5: Wait during switching between
segments.
W.IV1 to W.IV5: Wait within a segment interval.
W.SL1 to W.SL5: Segment switching (the controller
switches to a local setpoint when the segment is
completed after release.) (5 groups)
W.SR1 to W.SR5: Segment switching (the controller
switches to a remote setpoint when the segment is
completed after release.) (5 groups)
PLK.1 to PLK.30 (PLK.99): Linked to patterns 1 to 30 (99).
INS.: Allows a segment to be added to the end of a
speciedsegment.
DEL.:Allowsaspeciedsegmenttobedeleted.
PROG
9.13EditingtheProgramPattern
