13-6
IM 05P02C41-01EN
13.1.4 ChangingEventDisplay
Description
The UP55A has eight event (EV) lamps.
PV events are assigned to EV1 to EV8 lamps on the front of the controller.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange
Menu
symbol
EV1to
EV8
EV1 to EV8
display
condition
registration
PRO
Setting range: 4001 to 6304
OFF: Disable
4785: Link to PV event 1 (Lit when the PV
event-1 occurs)
4786: Link to PV event 2 (Lit when the PV
event-2 occurs)
4787: Link to PV event 3 (Lit when the PV
event-3 occurs)
4789: Link to PV event 4 (Lit when the PV
event-4 occurs)
4790: Link to PV event 5 (Lit when the PV
event-5 occurs)
4791: Link to PV event 6 (Lit when the PV
event-6 occurs)
4793: Link to PV event 7 (Lit when the PV
event-7 occurs)
4794: Link to PV event 8 (Lit when the PV
event-8 occurs)
4529: Heater break alarm 1 (Lit when the alarm occurs)
4530: Heater break alarm 2 (Lit when the alarm occurs)
5025 to 5027: Link to DI1-DI3 (Lit when the
contact is closed)
5041 to 5046: Link to DI11-DI16 (E1-terminal
area) (Lit when the contact is closed)
5057 to 5062: Link to DI21-DI26 (E2-terminal
area) (Lit when the contact is closed)
5073 to 5077: Link to DI31-DI35 (E3-terminal
area) (Lit when the contact is closed)
5089 to 5094: Link to DI41-DI46 (E4-terminal
area) (Lit when the contact is closed)
5153 to 5155: Link to AL1-AL3 (Lit when the
contact is closed)
5169 to 5173: Link to DO11-DO15 (E1-terminal
area) (Lit when the contact is closed)
5185 to 5189: Link to DO21-DO25 (E2-terminal
area) (Lit when the contact is closed)
5201 to 5205: Link to DO31-DO35 (E3-terminal
area) (Lit when the contact is closed)
5217 to 5221: Link to DO41-DO45 (E4-terminal
area) (Lit when the contact is closed)
For other functions, see the UTAdvanced
Series Communication Interface User’s
Manual.
DISP
Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
13.1SettingDisplayFunctions
