15-2
IM 05P02C41-01EN
15.2
PowerFrequencySetting
Description
The power frequency can be set by automatic detection or manually
.
However
, when the /DC option is specified, only manual setting is available. Set the
range to the commercial frequency of the installation location.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange
Menusymbol
FREQ
Power frequency
EASY
AUTO
60:60Hz
50:50Hz
SYS
384
386
