YOKOGAWA UP55A User Manual

v
IM 05P02C41-01EN
CheckingtheContentsofthePackage
Unpack the box and check the contents before using the product. If the product is
different from that which you have ordered, if any parts or accessories are missing, or if
the product appears to be damaged, contact your sales representative.
UP55A Main Unit
The UP55A main units have nameplates affixed to the side of the case.
Check the model and suffix codes inscribed on the nameplate to confirm that the product
received is that which was ordered.
No. (Instrument number)
When contacting your sales representative, inform them of this number, too.
ModelandSuffixCodesofUP55A(forStandardCodeModel)
Model Suffixcode
Optional
suffix
code
Description
UP55A
Program Controller (Power supply: 100-240 V AC)
30 program patterns / 300 program segments (99 program patterns / 600
program segments when the option /AP is specifed. Max. 99 segments per
pattern) (provided with retransmission output or 15 V DC loop power supply, 8
DIs, and 8 DOs)
Type 1:
Basic
control
-0 Standard type
-1 Position proportional type
-2 Heating/cooling type
Type 2:
Functions
0 None
1 Remote (1 additional aux. analog) input, 1 additional DI
2 RS-485 communication (Max.19.2 kpbs, 2-wire/4-wire)
3 10 additional DOs (*1)
4 3 additional aux. analog inputs, 2 DIs and 5 DOs to be deleted
Type 3:
Open networks
0 None
1 RS-485 communication (Max.38.4 kbps, 2-wire/4-wire)
2 Ethernet communication (with serial gateway function)
3 CC-Link communication (with Modbus master function)
4 PROFIBUS-DP communication (with Modbus master function)
5 DeviceNet communication (with Modbus master function)
Display language (*2)
-1 English (Default. Can be switched to other language by the setting.)
-2 German (Default. Can be switched to other language by the setting.)
-3 French (Default. Can be switched to other language by the setting.)
-4 Spanish (Default. Can be switched to other language by the setting.)
Case color
0 White (Light gray)
1 Black (Light charcoal gray)
Fixed code -00 Always “-00” (for Standard Code Model)
Optional suffix codes
/AP 69 additional patterns/300 additional segments
/DR
Additional direct input (TC and 3-wire/4-wire RTD) and current input to Remote
(1 additional aux. analog) input, 1 DI to be deleted (*3)
/HA Heater break alarm (*4)
/DC Power supply 24 V AC/DC
/CT Coating (*5)
*1: When the Type 2 code is “3”, only “0” can be specified for the Type 3 code.
*2: English, German, French, and Spanish are available for the guide display.
*3: The /DR option can be specified only when the Type 2 code is “1” or “4.”
*4: The /HA option can be specified only when the Type 1 code is “-0.”
*5: When the /CT option is specified, the UP55A does not conform to the safety standards (UL
and CSA) and CE marking. (Products with /CT option are not intended for EEA-market)
