YOKOGAWA UP55A User Manual

10-16
IM 05P02C41-01EN
10.11SettingRetransmissionOutputTerminal,Type,
andScales
Description
The OUT (O1RS) and OUT2 (O2RS) terminals can be used as retransmission output
when control output is not assigned to them.
Confirm the output type selection (OT) before setting the retransmission output. The
range can be changed.
► Controloutputterminal:10.1SettingControlOutputType
► Currentoutputrange:10.14ChangingCurrentOutputRange
20 mA (output signal)
0.0 °C 200.0 °C
4 mA
50.0 °C 150.0 °C
Retransmission scale
PV scale
Output range
Minimum value of
PV input range
Maximum value of
PV input range
To Recorder
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
RTS
Retransmission
out type of
RET
EASY
OFF: Disable
PV1: PV
SP1: SP
OUT1: OUT (Valve opening: 0 to 100
% in Position proportional control)
LPS: 15 V DC loop power supply
PV2: Loop-2 PV
SP2: Loop-2 SP
OUT2: Loop-2 OUT
TSP1: Target SP
HOUT1: Heating-side OUT
COUT1: Cooling-side OUT
MV1: Position proportional output
(internal computed value)
TSP2: Loop-2 target SP
HOUT2: Loop-2 heating-side OUT
COUT2: Loop-2 cooling-side OUT
MV2: Loop-2 position proportional
output (internal computed value)
PV: PV terminals analog input
RSP: RSP terminals analog input
AIN2: AIN2 terminals analog input
AIN4: AIN4 terminals analog input
OUT
