5-1
IM 05P02C41-01EN
Quick Setting Function
5
5.1 SettingUsingQuickSettingFunction
Description
The Quick setting function is a function to easily set the basic function of the controller.
The Quick setting function starts when the power is turned on after wiring.
The Quick setting function can be used only when the control mode is Single-loop
control. In other control modes, set the functions without using the Quick setting function.
The following lists the items to set using the Quick setting function.
(1) Control type (PID control, Heating/cooling control, etc.)
(2) Input function (PV input, range, scale (at voltage/current input), etc.)
(3) Output function (control output type and cycle time)
Chapter5QuickSettingFunction
