10-12
IM 05P02C41-01EN
10.8 CancelingOffsetofPVandSP(ManualReset)
Description
Manual reset can be used when the integral action is disabled.
When the integral action is disabled, there will be an offset of PV and SP. Manual reset
cancels this offset.
The manual reset value equals the output value when PV = SP is true.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
MR Manual reset EASY -5.0 to 105.0% PID
Note1: The PID number (1 to 8, or R) is displayed on Group display while each parameter is
displayed.
Note2: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
