13-12
IM 05P02C41-01EN
13.1.9  SelectingtheInitialOperationDisplaythatAppearsatPowerON
Description
The initial Operation Display that appears when the power is turned on can be set.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
HOME
Home Operation
Display setting
PRO
SP1: SP Display
SP2: Loop-2 SP Display
OUT1: OUT Display
OUT2: Loop-2 OUT Display
HCO: Heating/cooling OUT Display
VP: Valve Position Display
MV: Position Proportional Computation
Output Display
PID1: PID Number Display
PID2: Loop-2 PID Number Display
HC1: Heater Break Alarm-1 Current
Display
HC2: Heater Break Alarm-2 Current
Display
PV1: PV2/PV1 Display
PV2: PV1/PV2 Display
PV: PV Analog Input Display
RSP: RSP Analog Input Display
AIN2: AIN2 Analog Input Display
AIN4: AIN4 Analog Input Display
CS1 to CS5: SELECT Display 1 to 5
TSP1: TSP Display
TSP2: Loop-2 TSP Display
R.TIM: Remaining Segment-tim
Display
SEG.N: Segment Number Dispaly
R.CYC: Remaining Repetition Display
PTN: Program Pattern Display
AL5.8.1: Alarm-5 to -8 Status Display
AL5.8.2: Loop-2 Alarm-5 to -8 Status
Display
DISP
13.1SettingDisplayFunctions
