11.5 SettingAlarmOutputtoControlRelayTerminal
Description
The control relay terminal can be used for alarm output when it is not used for control
output.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
OR.S
OUT relay function
selection
STD
Same as the setpoint for the
contact output function.
See 12.2.1, “Setting Function of
Contact Output.”
ALM
OR.D
OUT relay contact
type
PRO
0: Closes the contact when an
event occurs
1: Opens the contact when an
event occurs.
OR2.S
OUT2 relay
function selection
STD Same as OR.S.
OR2.D
OUT2 relay contact
type
PRO Same as OR.D
Parameters and Corresponding Terminals
OR.S, OR.D OUT terminal
OR2.S, OR2.D OUT2 terminal
