YOKOGAWA UP55A User Manual

8-9
IM 05P02C41-01EN
Control Functions
8.1.2 CascadePrimary-loopControl
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
CTLM Control mode STD
SGL: Single-loop control
CAS1: Cascade primary-loop
control
CAS: Cascade control
PVSW: Loop control with PV
switching
PVSEL: Loop control with PV
auto-selector
CTL
 CAUTION
• Someparameterswillbeinitializedifthecontrolmode(CTLM)ischanged.
• When using the ladder program, the control mode cannot be changed.
Description
Cascade primary-loop control sets up a controller as the primary-loop controller when
two controllers are used for Cascade control.
It provides the output tracking function and FAIL output to the secondary-loop controller.
Cascade primary-loop control can be used for Standard type or Heating/cooling type
controller.
► PIDcontrol:8.2SettingControlType(CNT)
Uptofour10-segmentlinearizerapproximation/10-segmentlinearizerbiasescanbe
used for the input unit or output unit.
The Function block diagram describes only the basic functions.
Parameter symbols in the Function block diagram describe representative parameters.
For the functions and parameters which are not described in Function block diagram, see
the following.
► Contactinputassignment:12.1SettingContactInputFunction
► Contactoutputassignment:12.2SettingContactOutputFunction
► Contactoutputassignmenttoretransmissionoutputterminal:10.1SettingControlOutputType
► Analogoutputrangechange:10.14ChangingCurrentOutputRange
8
8.1SettingControlMode(CTLM)
