9-1
IM 05P02C41-01EN
Program Pattern Functions
9
9.1 SettingtheSettingMethodofProgramPattern
The segment setting method refers to an action control method within a segment.
The segment setting method is common to all program patterns.
Segment time can be selected between the two criteria below.
• Segment time setting
• Segment ramp-rate setting
 CAUTION
If the Segment Setting Method (SEG.T) parameter is changed, the program patterns
createdandstoredsofarwillbeallcleared(initialized)!!Becareful.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
SEG.T
Segment setting
method
EASY
TIME: Segment time setting
TM.RT: Segment ramp-rate setting
CTL
Chapter 9 Program Pattern Functions
