YOKOGAWA UP55A User Manual

10-17
IM 05P02C41-01EN
Output (Control and Retransmission) Functions
(Continued)
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
RTH
Maximum
value of
retransmission
output scale of
RET
STD
When RTS = PV1, SP1, PV2, SP2,
TSP1, TSP2, PV, RSP, AIN2, or AIN4,
RTL + 1 digit to 30000
-19999 to RTH - 1 digit
Decimal point position:
When RTS=PV1, SP1, or TSP1,
decimal point position is same as
that of PV input.
When RTS=PV2, SP2, or TSP2,
decimal point position is same as
that of RSP input.
When RTS=PV, decimal point position
is same as that of PV input scale.
When RTS=RSP, decimal point
position is same as that of RSP
input scale.
When RTS=AIN2, decimal point
position is same as that of AIN2
scale.
When RTS=AIN4, decimal point
position is same as that of AIN4
scale.
OUT
RTL
Minimum
value of
retransmission
output scale of
RET
STD
O1RS
Retransmission
output type of
OUT current
output
STD Same as RTS
O1RH
Maximum
value of
retransmission
output scale of
OUT current
output
STD
When O1RS = PV1, SP1, PV2, SP2,
TSP1, TSP2, PV, RSP, AIN2, or AIN4,
O1RL + 1 digit to 30000
-19999 to O1RH - 1 digit
Decimal point position:
When O1RS=PV1, SP1, or TSP1,
decimal point position is same as
that of PV input.
When O1RS =PV2, SP2, or TSP2,
decimal point position is same as
that of RSP input.
When O1RS =PV, decimal point
position is same as that of PV input
scale.
When O1RS =RSP, decimal point
position is same as that of
RSP input scale.
When O1RS =AIN2, decimal point
position is same as that of
AIN2 scale.
When O1RS =AIN4, decimal point
position is same as that of AIN4
scale
O1RL
Minimum
value of
retransmission
output scale of
OUT current
output
STD
10
10.11SettingRetransmissionOutputTerminal,Type,andScales
