YOKOGAWA UP55A User Manual

10-18
IM 05P02C41-01EN
(Continued)
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
O2RS
Retransmission
output type of
OUT2 current
output
STD Same as RTS
OUT
O2RH
Maximum
value of
retransmission
output scale of
OUT2 current
output
STD
When O2RS = PV1, SP1, PV2, SP2,
TSP1, TSP2, PV, RSP, AIN2, or AIN4,
O2RL + 1 digit to 30000
-19999 to O2RH - 1 digit
Decimal point position:
When O2RS=PV1, SP1, or TSP1,
decimal point position is same as
that of PV input.
When O2RS =PV2, SP2, or TSP2,
decimal point position is same as
that of RSP input.
When O2RS =PV, decimal point
position is same as that of PV input
scale.
When O2RS =RSP, decimal point
position is same as that of RSP
input scale.
When O2RS =AIN2, decimal point
position is same as that of AIN2
scale.
When O2RS =AIN4, decimal point
position is same as that of AIN4
scale.
O2RL
Minimum
value of
retransmission
output scale of
OUT2 current
output
STD
Setpoints PV2, SP2 and OUT2: Can be used in Cascade control.
Setpoints HOUT1 and COUT1: Can be used in Heating/cooling control.
Setpoint MV1: Can be used in Position proportional control.
(When opening or closing a valve by key operation in manual mode opration, the transmission
output becomes -5.0 %.)
Setpoint TSP2: Can be used in Cascade control.
Setpoints HOUT2 and COUT2: Can be used in Cascade control of Heating/cooling type.
Setpoint MV2: Can be used in Cascade control of Position proportional type.
(When opening or closing a valve by key operation in manual mode opration, the transmission
output becomes -5.0 %.)
Setpoint RSP: Can be used when equipped with remote input.
Setpoints AIN2 and AIN4: Can be used when the UP55A suffix code: Type 2 = 4.
Parameters and Corresponding Terminals
RTS, RTH, RTL RET terminal
O1RS, O1RH, O1RL OUT terminal
O2RS, O2RH, O2RL OUT2 terminal
10.11SettingRetransmissionOutputTerminal,Type,andScales
