YOKOGAWA UP55A User Manual

18-20
IM 05P02C41-01EN
10-segmentLinearizerSettingMenu(Menu:PYS1toPYS4)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
PYS
10-segment
linearizerselection
Group 1, 2:
STD
Group 3, 4:
PRO
OFF: Disable
PV: PV analog input
RSP: RSP analog input
AIN2: AIN2 analog input
AIN4: AIN4 analog input
PVIN: PV input
OUT: OUT analog output
OUT2: OUT2 analog output
RET: RET analog output
PV
(CTLM: SGL)
A1toA11
10-segment
linearizerinput1to
11
Group 1, 2:
STD
Group 3, 4:
PRO
-66.7 to 105.0% of input range (EU)
Outputlinearizer:-5.0to105.0%
0.0%
B1toB11
10-segment
linearizeroutput1
to 11
Group 1, 2:
STD
Group 3, 4:
PRO
10-segmentlinearizerbias:-66.7
to 105.0% of input range span
(EUS)
10-segmentlinearizer
approximation: -66.7 to 105.0%
of input range (EU)
Outputlinearizer:-5.0to105.0%
0.0%
PMD
10-segment
linearizermode
Group 1, 2:
STD
Group 3, 4:
PRO
0:10-segmentlinearizerbias
1:10-segmentlinearizer
approximation
0
10-segmentlinearizerparameters are four groups, the group number (1 to 4) is displayed on Group
display.
Initialvalueofeachcontrolmode
Control mode Group-1PYS Goup-2PYS Group-3and-4PYS
Single-loop control PV OFF OFF
Cascade primary-loop control PV OFF OFF
Cascade control PV RSP OFF
Loop control with PV switching PV OFF OFF
Loop control with PV auto-selector PVIN OFF OFF
18.2ListofParameters
