9-34
IM 05P02C41-01EN
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
JC
Junction
code
STD
CONT: Switching for continuation
HOLD: Hold-on switching (the controller holds
the end-of-segment setpoint when the
segment is completed, to perform control).
LOC: Local-mode switching (the controller
switches to a local setpoint when the segment
is completed).
REM: Remote-mode switching (the controller
switches to a remote setpoint when the
segment is completed).
W.SW1 to W.SW5: Wait during switching
between segments.
W.IV1 to W.IV5: Wait within a segment interval.
W.SL1 to W.SL5: Segment switching (the
controller switches to a local setpoint when
the segment is completed after release.) (5
groups)
W.SR1 to W.SR5: Segment switching (the
controller switches to a remote setpoint when
the segment is completed after release.) (5
groups)
PLK.1 to PLK.30 (PLK.99): Linked to patterns 1
to 30 (99).
INS.: Allows a segment to be added to the end of
aspeciedsegment.
DEL.:Allowsaspeciedsegmenttobedeleted.
PROG
9.8SettingtheOperationinSegmentSwitching
To Next Page
