YOKOGAWA UP55A User Manual

10-32
IM 05P02C41-01EN
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
RTS
Retransmission
output type of RET
EASY
OFF: Disable
PV1: PV
SP1: SP
OUT1: OUT (Valve opening: 0 to
100 % in Position proportional
control)
LPS: 15 V DC loop power supply
PV2: Loop-2 PV
SP2: Loop-2 SP
OUT2: Loop-2 OUT
TSP1: Target SP
HOUT1: Heating-side OUT
COUT1: Cooling-side OUT
MV1: Position proportional output
(internal computed value)
TSP2: Loop-2 target SP
HOUT2: Loop-2 heating-side OUT
COUT2: Loop-2 cooling-side OUT
MV2: Loop-2 position proportional
output (internal computed
value)
PV: PV terminals analog input
RSP: RSP terminals analog input
AIN2: AIN2 terminals analog input
AIN4: AIN4 terminals analog input
OUT
O1RS
Retransmission
output type of OUT
current output
EASY
O2RS
Retransmission
output type of
OUT2 current
output
EASY
Parameters and Corresponding Terminals
RTS RET terminal
O1RS OUT terminal
O2RS OUT2 terminal
10.17Using15VDCLoopPowerSupply
