Display, Key, and Security Functions
13
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
PCMD
Active color PV
display switch
EASY
0: Fixed in white
1: Fixed in red
2: Link to alarm 1 (Alarm OFF:
white, Alarm ON: red)
3: Link to alarm 1 (Alarm OFF:
red, Alarm ON: white)
4: Link to alarm 1 or 2 (Alarm
OFF: white, Alarm ON: red)
5: Link to alarm 1 or 2 (Alarm
OFF: red, Alarm ON: white)
6: PV limit (Within range: white,
Out of range: red)
7: PV limit (Within range: red, Out
of range: white)
8: SP deviation (Within deviation:
white, Out of deviation: red)
9: SP deviation (Within deviation:
red, Out of deviation: white)
10: Link to DI (ON: red, OFF:
white)
DISP
PCH
PV color change
high limit
EASY
Set a display value when in PV
limit or SP deviation.
-19999 to 30000 (Set a value
within the input range.)
Decimal point position depends on
the input type.
PCL
PV color change
low limit
EASY
Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
13.1SettingDisplayFunctions
