13-27
IM 05P02C41-01EN
Display, Key, and Security Functions
ParameterY000
Displayeddigit bit Description
1st digit
0 AL1 status (0: OFF, 1: ON)
1 AL2 status (0: OFF, 1: ON)
2 AL3 status (0: OFF, 1: ON)
3 –
2nd digit
4 –
5 –
6 –
7 –
3rd digit
8 –
9 –
10 –
11 –
4th digit
12 –
13 –
14 –
15 –
ParameterY100
Displayeddigit bit Description
1st digit
0 DO11 status (0: OFF, 1: ON)
1 DO12 status (0: OFF, 1: ON)
2 DO13 status (0: OFF, 1: ON)
3 DO14 status (0: OFF, 1: ON)
2nd digit
4 DO15 status (0: OFF, 1: ON)
5 –
6 –
7 –
3rd digit
8 –
9 –
10 –
11 –
4th digit
12 –
13 –
14 –
15 –
ParameterY200
Displayeddigit bit Description
1st digit
0 DO21 status (0: OFF, 1: ON)
1 DO22 status (0: OFF, 1: ON)
2 DO23 status (0: OFF, 1: ON)
3 DO24 status (0: OFF, 1: ON)
2nd digit
4 DO25 status (0: OFF, 1: ON)
5 –
6 –
7 –
3rd digit
8 –
9 –
10 –
11 –
4th digit
12 –
13 –
14 –
15 –
13
13.4ConfirmationofKeyandI/OConditionandVersion
