YOKOGAWA UP55A User Manual

17-14
IM 05P02C41-01EN
AdditionalContactInputAccordingtotheUP55ASuffixCodes
Sufxcodes(forStandardmodel):Type2=1or4;however,withoutoptionalsufxcode/DR
Optionalsufxcode(forDetailedmodel):/R1
Non-voltagecontact Transistor contact
DI16
COM
Contact rating: 12 V DC, 10 mA or more
303
304
RSP
DI16
COM
303
304
Contact rating: 12 V DC, 10 mA or more
RSP
+5 V
+
–
Sufxcode(forStandardmodel):Type2=2
Optionalsufxcode(forDetailedmodel):/X1
Non-voltagecontact Transistor contact
DI11
DI12
DI13
DI14
DI15
COM
Contact rating: 12 V DC, 10 mA or more
301
302
303
304
305
306
DI
DI11
DI12
COM
DI13
DI14
DI15
301
302
303
304
305
306
DI
+5 V
+5 V
+5 V
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
+
+
+
–
Sufxcode(forStandardmodel):Type2=4
Optionalsufxcode(forDetailedmodel):/A2
Non-voltagecontact Transistor contact
DI26
COM
Contact rating: 12 V DC, 10 mA or more
309
310
AIN2
DI26
COM
309
310
AIN2
+5 V
Contact rating: 12 V DC, 10 mA or more
+
–
Sufxcode(forStandardmodel):Type2=4
Optionalsufxcode(forDetailedmodel):/A4
No-voltagecontact Transistor contact
DI46
COM
Contact rating: 12 V DC, 10 mA or more
503
504
AIN4
DI46
COM
503
504
AIN4
+5 V
Contact rating: 12 V DC, 10 mA or more
+
–
17.4Wiring
