YOKOGAWA UP55A User Manual

17-16
IM 05P02C41-01EN
Optionalsufxcode(forDetailedmodel):/W2
No-voltagecontact Transistor contact
DI21
DI22
COM
Contact rating: 12 V DC, 10 mA or more
307
308
309
DI
DI21
DI22
COM
307
308
309
DI
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
–
Optionalsufxcode(forDetailedmodel):/W3
No-voltagecontact Transistor contact
DI31
DI32
COM
Contact rating: 12 V DC, 10 mA or more
407
408
409
DI
DI31
DI32
COM
407
408
409
DI
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
–
Optionalsufxcode(forDetailedmodel):/W4
No-voltagecontact Transistor contact
DI41
DI42
COM
Contact rating: 12 V DC, 10 mA or more
501
502
503
DI
DI41
DI42
COM
501
502
503
DI
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
–
The function is assigned to contact inputs for each control mode and control type.
► InitialvalueofContactinputfunction:8.1SettingControlMode(CTLM)
► Contact input function registration: 12.1 Setting Contact Input Function
Note
If the /DR option is additionally specified to the remote input, the remote Input with direct input
can be used as remote input.
However, DI16 is to be deleted. (See 17.4.3 Remote (Auxiliary Analog) Input Wiring)
17.4Wiring
