18-2
IM 05P02C41-01EN
FunctionofEachMenu
Menusymbol Function
MODE
Operation mode (PROG/RESET/LOCAL/REM switch, Auto-tuning switch,
etc.)
The parameters in the menu of the following table indicate the parameters to set the
functions necessary for operation. The symbol in parentheses are shown on Group
display.
Menusymbol Function
CS SELECT parameter
PROG Program pattern setting function
LOC Local setting function
EDIT Editing function
AL Alarm setpoint
SPS SP-related function
ALRM Alarm function
PVS PV-related function
PID PID setting
TUNE
Super, Super 2, Sample PI control, non-linear PID control, anti-reset windup,
output velocity limiter, and manual preset output
ZONE Zone control
AL(LP2) Alarm setpoint (Loop 2)
ALRM(LP2) Alarm function (Loop 2)
PVS(LP2) PV-related function (Loop 2)
PID(LP2) PID setting (Loop 2)
TUNE(LP2)
Super, Super 2, non-linear PID control, anti-reset windup, output velocity
limiter, manual preset output (Loop 2)
ZONE(LP2) Zone control (Loop 2)
PPAR P parameter (for ladder program)
PYS1(1) 10-segmentlinearizer1
PYS2(2) 10-segmentlinearizer2
PYS3(3) 10-segmentlinearizer3
PYS4(4) 10-segmentlinearizer4
18.1ParameterMap
To Next Page
