YOKOGAWA UP55A User Manual

18-15
IM 05P02C41-01EN
Parameters
18
AlarmFunctionSettingMenu(Menu:ALRM)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
VT1toVT8
PV velocity
alarm time
setpoint 1 to 8
EASY 0.01 to 99.59 (minute.second) 1.00
HY1toHY8
Alarm-1 to -8
hysteresis
EASY
Set a display value of setpoint of
hysteresis.
-19999 to 30000 (Set a value within the
input range.)
Decimal point position depends on the
input type.
When the decimal point position for the
input type is set to "1", the initial value
of the hysteresis is "1.0".
10
DYN1to
DYN8
Alarm-1 to -8
On-delay timer
STD
0.00 to 99.59 (minute.second)
0.00
DYF1to
DYF8
Alarm-1 to -8
Off-delay timer
PRO 0.00
AMD Alarm mode STD
0: Always active
1: Not active in RESET mode
2: Not active in RESET or MAN mode
0
In Cascade control, the following parameters are also displayed for secondary loop. (the LP2 lamp
is lit)
• Parameter: VT1 to VT8 HY1 to HY8, DYN1 to DYN8, DYF1 to DYF8, AMD
PV-relatedSettingMenu(Menu:PVS)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
BS PV input bias EASY
-100.0 to 100.0% of PV input range
span (EUS)
0.0 % of PV
input range
span
FL PVinputlter EASY OFF, 1 to 120 s OFF
In Cascade control, the following parameters are also displayed for secondary loop. (the LP2 lamp
is lit)
Parameter: BS, FL
18.2ListofParameters
