3. To define a neighboring router with which to exchange
routing information, use neighbor command in RIP
configuration mode as shown in
Table 213 . To remove an
entry, use the no form of this command.
TABLE 213 NEIGHBOR COMMAND WINDOW
Command
Format
Command
Mode
Command Function
neighbor <ip-
address>
RIP Config This defines neighboring
router with which routing
information is exchanged
<ip-address> refers to IP address of a peer router with
which routing information exchanges.
This command permits the point-to-point (non-broadcast)
exchange of routing information, when use with combination
of passive-interface router configuration command, routing
information exchanges between a subset of routers and
access servers on a LAN.
Result: This configures a peer router with whom routing
information exchanges.
4. To enable authentication for RIP Version 2 packets and to
specify set of keys that uses on an interface, use ip rip
authentication key command in RIP interface configuration
mode as shown in
Table 214 . Use the no form of this
command to prevent authentication.
TABLE 214 IP RIP AUTHENTICATION KEY
Command
Format
Command
Mode
Command Function
ip rip
authentication
key <key>
RIP Interface
Config
This designates a key that
can be used for simple text
authentication of an
interface
<key> refers to authentication key in characters ranges
from <1- 16>.
This command specifies, to accept only those RIP update
packets coming from the peer that is authenticated.
Result: This configures authentication for RIP routing
updates.
5. To specify the type of authentication used in RIP Version 2
packets, use ip rip authentication mode command in RIP
interface configuration mode as shown in below table. Use
the no form of this command to restore clear text
authentication.
