ZXR10 GER (V2.6.03) General Excellent Router User Manual Volume-I
296 Confidential and Proprietary Information of ZTE CORPORATION
CE1(config-router)#neighbor 10.1.1.1 remote-as 100
CE1(config-router)#no auto-summary
Configuration of PE1:
PE1(config)#ip vrf test1
PE1(config-vrf)#rd 100:1
PE1(config-vrf)#route-target import 100:1
PE1(config-vrf)#route-target export 100:1
PE1(config)#interface loopback1
PE1(config-if)#ip address 10.10.1.1 255.255.255.255
PE1(config)#interface fei_1/1
PE1(config-if)#ip address 10.10.12.1 255.255.255.0
PE1(config-if)#mpls ip
PE1(config-if)#mpls ldp discovery transport-address
interface
PE1(config)#interface fei_1/2
PE1(config-if)#ip vrf forwarding test1
PE1(config-if)#ip address 10.1.1.1 255.255.255.0
PE1(config)#router ospf 1
PE1(config-router)#router-id 10.10.1.1
PE1(config-router)#
n
etwork 10.0.0.0 0.255.255.255 area
0.0.0.0
PE1(config)#router bgp 100
PE1(config-router)#neighbor 10.10.3.3 remote-as 100
PE1(config-router)#neighbor 10.10.3.3 update-source
loopback1
PE1(config-router)#address-family ipv4 vrf test1
PE1(config-router-af)#redistribute connected
PE1(config-router-af)#neighbor 10.1.1.2 remote-as 200
PE1(config-router-af)#exit-address-family
PE1(config-router)#address-family vpnv4
PE1(config-router-af)#neighbor 10.10.3.3 activate
PE1(config-router-af)#exit-address-family
PE1(config)#mpls ip
PE1(config)#mpls ldp router-id loopback1 force
An EBGP connection is set up between CE1 and PE1:
CE1#show ip bgp summary
BGP router identifier 10.1.1.2, local AS number 200
BGP table version is 8, main routing table version 8
Neighbor V AS MsgRcvd MsgSent TblVer InQ OutQ Up/Down
State/PfxRcd
10.1.1.1 4 100 156 157 8 0 0
