Chapter 20 MPLS VPN Configuration
Confidential and Proprietary Information of ZTE CORPORATION 301
Result: This displays VRF routing table.
Check the VRF routing table on PE1:
PE1#show ip route vrf test1
IPv4 Routing Table:
Dest Mask Gw Interface
Owner pri metric
10.1.1.0 255.255.255.0 10.1.1.1 fei
_
1/2
direct 0 0
10.1.1.1 255.255.255.255 10.1.1.1 fei
_
1/2
address 0 0
100.1.1.1 255.255.255.255 10.1.1.1 fei
_
1/2
bgp 20 0
10.10.10.0 255.255.255.0 10.10.3.3 fei
_
1/1 bgp
200 4294967295
200.1.1.1 255.255.255.255 10.10.3.3 fei_1/1 bgp
200 4294967295
PE1#
The VRF routing table contains directly connected network
sections, routes advertised by CE1 and routes advertised by
PE2.
Whether the peer can enter VRF depends upon whether the
import/export target route attribute (route-target
import/export) of both parties match each other.
5. To check whether the internal layer labels of VPN on PEs are
correct and consistent; use show ip protocol routing vrf
<vrf-name> command in privileged mode as shown in
Table
345.
TABLE 345 SHOW IP PROTOCOL ROUTING VRF COMMAND
Command
Format
Command
Mode
Command Function
show ip
protocol
routing vrf
<vrf-name>
Privileged
This checks internal layer labels
of VPN
Result: This checks internal layer labels of VPN.
Check the internal layer label that PE1 assigns to VPN routes:
