ZXR10 GER (V2.6.03) General Excellent Router User Manual Volume-I
18 Confidential and Proprietary Information of ZTE CORPORATION
Port Type Specifications
Category-3, 4 and 5 Unshielded Twisted Pairs (UTP)
Maximum transmission distance: 185m
100/1000Bas
e-T
In compliance with IEEE 802.3;
RJ45 connector
Category-5 Unshielded Twisted Pairs (UTP)
Maximum transmission distance: 100 m
Note: When the interface is connected with a host, straight-through
network cable is used; when it is connected with a hub, switch or
router, a crossover cable is used.
ZXR10 GER02/04 has a USB interface port for flash transferring.
ZXR10 GER08 has no USB interface.
SMP panel has multiple indicators whose functions are listed in
Table 9.
TABLE 9 SMP PANEL INDICATORS
Indicators Function Description
PWR
indicator
(green)
Power indicator. When it is on, it indicates that the
equipment has been powered on and the power supply
normally.
RUN
indicator
(green)
Running indicator. When it is on, it indicates that the
system runs normally.
ALM
indicator
(red)
Alarm indicator: Indicates a system fault when it is on.
NP
This indicates working status of the network
processor: This is constantly on when the processor is
working normally; This flashes if the processor fails;
This is off if the processor initializes unsuccessfully.
FAN
This indicates working status of the fan: This is
constantly on when the fan is working normally; This
flashes if the fan fails.
HOT
This indicates equipment inside temperature: This is
off when the equipment is working normally; this
flashes if the equipment fails.
MST
This indicates SMNP master/slave status: This is
constantly on in the master mode; this is off in slave
working status.
Dual-8
digitron
This indicates SMNP CPU working status; This is
displayed when the equipment works normally.
USB Interface
Indicators
