ZXR10 GER02/04 has a USB interface port for flash transferring.
SMP panel has multiple indicators whose functions are listed in
Table 14.
TABLE 14 SMP PANEL INDICATORS
Indicators Function Description
PWR indicator
(green)
Power indicator. When it is on, it indicates that the
equipment has been powered on and the power
supply normally.
RUN indicator
(green)
Running indicator. When it is on, it indicates that
the system runs normally.
ALM indicator
(red)
Alarm indicator: Indicates a system fault when it is
on.
NP
This indicates working status of the network
processor: This is constantly on when the processor
is working normally; This flashes if the processor
fails; This is off if the processor initializes
unsuccessfully.
FAN
This indicates working status of the fan: This is
constantly on when the fan is working normally;
This flashes if the fan fails.
HOT
This indicates equipment inside temperature: This is
off when the equipment is working normally; this
flashes if the equipment fails.
MST
This indicates SMNP master/slave status: This is
constantly on in the master mode; this is off in
slave working status.
Dual-8
digitron
This indicates SMNP CPU working status; This is
displayed when the equipment works normally.
SMNP board contains two buttons. Their functions are listed in
Table 15.
TABLE 15 SMNP BUTTONS FUNCTIONS
Buttons Function Description
RST
If SMNP master board reset button is pressed in the
presence of SMNP slave, master/slave SMNP switchover
will occur. If there is no slave SMNP, then equipment
will be reset. If SMNP slave has RST button, SMNP slave
will be reset.
EXCH
Using EXCH button, SMNP board master/slave switches
over master/slave function. There is no response if this
button presses on SMNP slave.
USB Interface
Indicators
Buttons
