ZXR10 GER (V2.6.03) General Excellent Router User Manual Volume-I
74 Confidential and Proprietary Information of ZTE CORPORATION
Input "c" in the Boot status and press <ENTER> to enter into
parameter modification status as shown in
Table 62.
Result: Parameter modification status window is displayed
5. Change the boot mode to "Boot from the background
TFTP"; change the address of the TFTP Server to
corresponding TFTP Server Computer System IP address as
shown in
Table 62.
Result: Boot mode is changed from normal boot to TFTP
boot.
6. Change Client address and gateway address to address of
built-in Ethernet interface and configure corresponding
subnet mask as shown in
Table 62.
TABLE 62 VERSION UPGRADING COMMAND WINDOW
Result: The following prompt "[ZXR10 Boot]:" appears
7. Enter “@” and press <ENTER>, System boots with the image
from the background TFTP Server automatically as shown in
below table.
[ZXR10 Boot]:c
'.' = clear field; '-' = go to previous field; ^D = quit Boot
Location [0:Net,1:Flash] : 0 (0 indicates booting from the
background TFTP, and 1 indicates booting from the FLASH)
Client IP [0:bootp]: 168.4.168.168 (Corresponding to the
address of the management Ethernet port) Netmask:
255.255.0.0
Server IP [0:bootp]: 168.4.168.89 (Corresponding to the
address of the background TFTP Server)
Gateway IP: 168.4.168.168 (The gateway address is the
address of the management Ethernet port)
Boot Path: zxr10.zar (Use the default value)
Enable Password:(Use the default value)
Enable Password Confirm:(Use the default value)
[ZXR10 Boot]:
[ZXR10 Boot]:@
Loading... get file zxr10.zar[15922273] successfully!
file size 15922273.
...
Start ZXR10-TSR MPU
Version V1.2.m.n Built at Mar 22 2004, 11:03:18
Synchronizing .................... .........................OK!
