2.2.3 Working range
Illustration, working range IRB 14000
The illustrations show the unrestricted working range of the robot.
Front view
0
347
593
1018
94
0
14
451 235
664
Z
Y
xx1500000105
Continues on next page
Product manual - IRB 14000 65
3HAC052983-001 Revision: D
