7.16.2.2
Automatic continuous movements program (Exhibitions)
1.
Switch ON the unit.
2.
When the keyboard green LED blinks slowly (one pulse per second), press the
>0< button and wait the end of the axis reset.
3.
Press together the column up and column down buttons on the keyboard.
(Make sure that the 3D sensor is closed in 3D panoramic position).
4.
After 5 second release both buttons to start the automatic demo sequence.
5.
The unit then keeps on doing a demo sequence of a panoramic roto-
translation, a ceph movement and a column movement.
6.
In order to stop the movements, switch OFF the unit.
Note
To stop the columns movements, press the red emergency button located
on the upper part of the unit, near the power switch.
