offsets reported in the equipment parameters table (see paragraph 14.1)
following the procedures present on paragraph 8.4.
3.
If the error persists, replace MCU board complete of EEPROM (see paragraph
11.3.2). Manually restoring of the unit configuration data will be requested as
explained in the above points.
Technical Service additional information required
: MCU SD card log (see paragraph
11.2.1.2).
9.2.2.2
E102: Wrong version number in configuration area
This error is shown when the version number of the configuration area doesn’t
match the MCU board firmware version.
1.
Verify that the code printed on the MCU board match code 5804040700/XX. If
it does not match, replace the MCU board with a correct one (see paragraph
11.3.2).
2.
Contact Technical Service to verify that the MCU firmware version is compatible
with the unit configuration. If it is not, upload the MCU firmware with a
compatible one (see paragraph 11.1.1).
3.
If the problem is still present, reset the EEPROM following the procedure
described in paragraph 9.2.2.1, point 2.
Technical Service additional information required
: MCU SD card log (see paragraph
11.2.1.2).
9.2.2.3
E103: Timeout error occurred during an EEPROM erase
operation /
E104: Timeout error occurred during an EEPROM write
operation
These errors are shown when a timeout occurred during an EEPROM erase or write
operation.
Power OFF the unit and, after 1 minute delay, power it ON again and verify the
correct functioning of the unit.
If a new error is displayed, refer to the specific error paragraph description to fix
the issue.
