11.2.1.2 MCU logs
Note
The SD card MUST has the following characteristics:
- Capacity ≤ 32Gb
- Formatted as FAT32.
This log record the events that occurs during the MCU firmware execution, even if
the unit is not connected to the computer.
1. Insert an SD card in the MCU SD card reader.
2. Switch ON the unit.
3. Wait at least 30s (10 minutes if sensor power on issues occur, related to sensors
overheating) or use the unit normally, or reproduce the error/problem to be
logged.
4. Switch OFF the unit.
5. Read the SD card. The “Logs” folder contents the following files:
- eeprom.dump
- mcu.log
The main information listed in the “mcu.log” file are:
Log
Description
MCU version numbers
MCU Firmware (SW) version
DIP switch code
MCU DIP-Switches position (see paragraph
4.2.2.1)
0 = Normal mode
S/N
MCU hardware key number (U.I.C.)
Acquisition mode
Area mode / DTDI
Tubehead type
2D / 3D
Machine offsets
MCU IP = 192.168.0.211
Netmask = 255.255.255.0
MCU Ethernet IP and Netmask addresses
XP-PACK option
XP exam option ENABLED or DISABLED
XCU version numbers
Generator board Firmware (SW) version
CCU version numbers
CCU board Firmware(SW) version
Sensor temperature
