11.2.1.3 CCU logs
Note
The SD card MUST has the following characteristics:
- Capacity ≤ 32Gb
- Formatted as FAT32.
This log record the events that occurs during the CCU firmware execution, even if
the unit is not connected to the computer.
1. Insert an SD card in the MCU SD card reader.
2. Switch ON the unit.
3. Wait at least 30s (10 minutes if sensor power on issues occur, related to sensors
overheating) or use the unit normally, or reproduce the error/problem to be
logged.
4. Switch OFF the unit.
5. Read the SD card. The “Logs” folder contents the following files:
- eeprom.dump
- ccu.log
The main information listed in the “mcu.log” file are:
Log
Description
CCU version numbers
CCU Firmware (SW) version
Nasion potentiometer readout
DIP switch code
CCU DIP-Switches position (see paragraph
4.2.2.1)
0 = Normal mode
Position of the imaging detector
