Service Manual – Technical characteristics
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
45
Mechanical characteristics
Focal spot to image receptor distance
(panoramic and 3D)
52 cm (20")
Focal spot to image receptor distance
(cephalometric)
165 cm (65")
Telescopic motorised column run
70 cm (27"1/2)
Maximum total height
223 cm (88")
Weight
123 kg (271 lbs)
Environmental conditions
Minimum room size (please refer to
the Service Manual)
186 x 121 cm (75"x49")
Recommended room size (please refer
to the Service Manual)
200 x 130 cm (80"x52")
Working temperature range
+ 10°C ÷ + 35°C
Working relative humidity (RH) range
30% ÷ 75%
Working atmospheric pressure range
700 ÷ 1060 hPa
Temperature range for transport and
storage
- 20°C ÷ + 70°C
Humidity range for transport and
storage
< 95% without condensation
Minimum atmospheric pressure for
transport and storage
630 hPa
Note
The handles of the equipment are covered with a special antibacterial paint
which, thanks to the emission of silver ions, reduces the development of
micro-organisms.
