Nominal maximum voltage
110 kVp
Filament max current
4 A
Filament max voltage
6.7 V
Anode thermal capacity
30 kJ
Anode thermal capacity during
continuous operation
300 W
Laser centering devices
2 laser beams are used for patient positioning; beams that align the sagittal and
Frankfurt planes (please refer to relevant paragraphs for a detailed explanation).
Wave length
650 nm
Divergence
< 2.0 mRad
Optical power on the working surface
< 1 mW
Laser class
Class 2 laser product according to IEC
standard 60825-1:2007
3D Digital sensor
Detector type
CMOS flat panel
Sensitive Area (H x L)
144 x 118.6 mm
Pixel dimensions
120 µm
240 µm (2x2 binning)
Number of pixels (H x L)
1200 x 988
600 x 494 (2x2 binning)
Voxel dimensions
175 µm HD mode
87.5 µm XD mode
Grey levels
65536 (16 bit)
Resolution
4.16 lp/mm (non binning mode)
Sensor cover attenuation equivalent
< 0.4 mm Al eq.
Cephalometric Digital sensor
Detector type
CMOS sensor
Sensitive Area (H x L)
228 x 6.7 mm
Pixel dimensions
99 µm
198 µm (2x2 binning)
Number of pixel (H x L)
2304 x 68 (non-binning mode)
Grey levels
16384 (14 bit)
Resolution (spatial frequency at
CTF=5%)
5 lp/mm (non-binning mode)
Sensor cover attenuation equivalent
< 0.4 mm Al eq.
