Service Manual Installation
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
73
6.
If necessary, mark the holes for fixing the base to the floor.
7.
Move back the packaging, drill the wall and, if necessary, the floor, put the
dowels, reposition the packaging against the wall and secure the wall bracket
and the base plate with the screws.
Mark the holes on the floor
