Service Manual – Installation
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
80
Figure 16
13.
Fit the two joint locking plates using the same screws that fix the hinge.
Figure 17
Store the hinges here
for future use
