Service Manual – Installation
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
83
16.
Remove the rotation locking bracket
being careful not to hit the optical
sensor near here.
Figure 22
Figure 23
Rotation locking bracket
