12.The marker 1 (maximum) and marker 2 (minimum) readings should be within the
specified range for each power level with reference to the fixed marker value.
13.If your analyzer does not have Option 006: this completes the test.
If your analyzer has Option 006: go to “Power Meter Calibration from 3 GHz to 6 GHz,”
next.
Power Meter Calibration from 3 GHz to 6 GHz
1. Connect the equipment as shown in Figure 2-61 using the 8481A power sensor.
2. Press .
3. Press .
4. Press . Press the appropriate softkeys
to build a sensor calibration factor table for the 8481A power sensor (sensor B).
5. Press to exit the sensor calibration factor entries menu.
6. Press to select the 8481A sensor. Press
.
7. Press to start the power
meter calibration.
Output Power Linearity Measurement from 3 GHz to 6 GHz
1. Set up the equipment as shown in Figure 2-62.
2. Press .
3. Press .
4. Press
.
5. Press (or the next power setting from the performance test record).
6. Press .
7. Press
.
8. Read the value for marker 1 from the display and enter it in the performance test
record in the “Marker 1 (Maximum)” column. Enter the value of marker 2 in the
“Marker 2 (Minimum)” column.
9. Press
(or the next power setting from the performance test record) .
Start 3 G/n Stop 6
Cal
Sweep Setup
Cal
Display
Marker
3 G/n
x1
∆
∆
Power −15 x1
Marker
Marker Search
Marker
Marker
−13
x1
To Next Page
